NIO 100 – an IoT (Internet of Thing) gateway for cloud application specifically focused in industrial field.
NIO 100 collects sensor data via RS232/485/DIO and transmitting data to cloud by 3G,WiFi or Ethernet. NIO 100 has power9~36V wide range DC inputs for industrial environment. NIO 100 is an Innovative and compactable new gateway for IoT target market to Industrial 4.0.
NEXCOM’s latest NIO 100 series provides seamless interconnection and secured data transmission from edge devices to the cloud. NIO 100 series has built connectivity, manageability, and security into a cloud-ready IoT gateway solution. Combining the support for diverse communication and extended operating temperature, NIO 100 series offers flexible use in manufacturing, industrial, environmental monitoring, and home and building automation applications.
NIO 100 series has integrated Intel® Quark™ SoC X1021, Wind River® Intelligent Device Platform, and McAfee Embedded Control. To connect the edge to the cloud, NIO 100 series supports multiple communication protocols with fieldbus IoT gateway NIO 101—with broad support for PROFIBUS, PROFINET, DeviceNet, EtherNet/IP, EtherCAT, and Modbus TCP/RTU—and Modbus TCP/RTU IoT gateway NIO 100. NIO 100 series can also build up ZigBee, Z-Wave, and EnOcean connectivity with custom configuration. The multi-protocol support allows NIO 100 to collect data from manufacturing machines and wireless sensor networks (WSN). Moreover, NIO 100 series can transfer data over both wired and 3G/Wi-Fi wireless networks, offering the last mile connection and ensuring reliable data transmission with data buffering.
To increase manageability, NEXCOM‘s IoT Studio and Connect-to-Cloud cloud server (C2C cloud server) offer hassle-free configuration and management from initial setups to system fine-tuning afterwards. NEXCOM IoT Studio is a GUI utility tool which simplifies network configuration with click-to-connect settings, updates gateways via wireless automatic over the air (OTA) updates, and enables rapid and consistent maintenance with group management. The upcoming C2C cloud server—featuring devices, data, access, and event management functions—allows manufacturers, plant operators, and facility managers to remotely monitor and control everyday operations to make more efficient and productive use of assets.
To protect system and data integrity, NIO 100 IoT gateway solution provides both hardware- and software-level security with Intel processor, Wind River® Intelligent Device Platform, and McAfee Embedded Control. For instance, NIO 100 uses secure boot to provide a verified environment for software and applications to load; it prevents data tampering or malware attacks during transmission with VPN and firewall; and it blocks unauthorized change attempts with a whitelisting approach.
- Onboard single-core Intel® Quark™ SoC X1021
- Memory : DDR3 1GB
- eMMC 4GB
- 4 x 4 DIO supports
- Wind River® Intelligent Device Platform based on Wind River® Linux and McAfee Embedded Control (NIO 100/101)
- Web GUI management
- Xcare client
- Yocto-based BSP (NIO 100Y/101Y)
- Support Modbus TCP/RTU
- 1x mini-PCIe on NIO 100/100Y for optional 3G/Wi-Fi module
- 2x mini-PCIe on NIO 101/101Y for FBI and optional 3G/Wi-Fi modules
- 2x 10/100 Ethernet ports, 2x USB, 1x RS232/422/485
- Built-in secure boot function
- Wide power input range of 9~36V DC
- Extended operating temperature from -20 to 70 degree Celsius
- Wall Mounting
- 110 x110 x 60mm
