PoE Solutions
Home » Products » Homeland Security Solutions » PoE Solutions
  • Integrated PoE solutions
  • Mobile PoE Switches
In response to increased global demand for intelligent surveillance solutions, NEXCOM has introduced NViS series of integrated PoE and intelligent hybrid embedded DVR/NVR systems, which provide the perfect solution for security protection. With the NEXCOM all-in-one server board, customers are able to save time and cost as well as fulfill demands of CCTV and IP surveillance in the marketplace.
Integrated with cutting-edge Intel technology, NEXCOM's hybrid surveillance system implements advanced intelligent video analysis (IVA) which is capable of handing multiple threads at the same time. For instance, tasks such as flow counting, privacy masking and missing object detection can rapidly be performed.

The NViS 2140/ 2280/ 3540/ 5240 series with built in Intel® Atom™ processor, features a compact and energy-efficient design. Incorporating POE and power ignition technology, the three series eradicates the difficulties associated with providing different power sources to devices such as IP camera in buses, police cars, sightseeing buses, and school buses etc. The NViS 7280 series supports a wide range of Intel® Dual Core or Quad Core CPUs. Embedded with high quality video/ audio capture chips, NViS series is the best design for security surveillance.

NViS Series Main Features



  • Industrial-level for PC-based DVR

  • Embedded video decoder chips on motherboard provides steadier and easier operation

  • Fanless design improves reliability and eliminates systems failure caused by fan breakdown to retain low maintenance cost

  • Power over Ethernet (PoE) device connection

  • Hybrid surveillance enrich IVA applications

  • Integrated with power ignition

  • Wide range of DC input from 9V to 36 V for mobile surveillance


nvis
in-vehicle PoE switches to simplify the installation of in-vehicle technology to address the growing need for onboard mobile video surveillance and internet connectivity. The fanless VES30-8S and VES30-4S feature 802.3af PoE ports and smart power management. The in-vehicle PoE switches can streamline the wiring of powered devices and provide protection against transient power fluctuation and other challenges in vehicular environments, keeping including IP cameras, Wi-Fi access points, and VoIP phones in good shape.
The VES30-8S and VES30-4S are in-vehicle PoE switches with eight and four full 802.3af compliant PoE ports. With each port offering 15.4 watts of power, the in-vehicle PoE switches facilitate device integration by eliminating the need for separate power lines and can easily bring, for instance Ethernet service onboard to enhance passenger experience or incorporate surveillance cameras to strengthen the safety and security of dangerous or valuable goods handling.
As the power source from a vehicle is unstable by nature, the in-vehicle PoE switches support a wide voltage range of 9V to 36V and provide smart power management with low battery voltage protection, power-on and power-off delay settings, and automatic power-on on ignition features. These unique features can ensure reliable operation and prevent premature failure of both the in-vehicle PoE switches and powered devices.
Dedicated to vehicle applications, the VES30-8S and VES30-4S are encased in a fanless dustproof enclosure and can operate under shock, vibration, and temperature extremes from -30 to 70°C. The in-vehicle PoE switches are also small in size and support din rail mounting for ease of installation.

Main Features



  • 4/8x 10/100/1000 Mbps PoE port (full 802.3af compliance)

  • 1x 10/100/1000 Mbps LAN port

  • 48VDC, 15.4 watts per PoE port

  • Wide power input range 9~36VDC

  • -30 ~ 70°C operating temperature

  • Low battery voltage protection

  • Power on/off delay time setting

  • Ignition power on/off support

  • CE/FCC, E13 mark certification


poeswitch
